Product Overview
Flow Edge 4ch - 1RU 4K Up/Down/Cross Converter
The Flow Edge 4-Channel Rackmount 4K Up/Down/Cross Converter by SCIENCE IMAGE combines the adaptability of the popular Flow 4K and Flow 2 converters, condensing them into a single rack unit with centralized power. This simplifies the process of constructing a multi-source, multi-destination rack kit.
With Flow Edge, users can handle up to four channels of up/down and cross conversion for virtually any video format up to 4K at 60 fps, utilizing HDMI 2.0 and 12G-SDI connections. Each channel of the Flow Edge comes equipped with its own dedicated LED screen, menu control wheel, network port, video input/output, audio input/output, and power button. The Flow Edge is enclosed within a compact 1 RU, short-depth chassis.
Features at a Glance
- 4-channel rackmount 4K 12G-SDI/HDMI up/down/cross converter with fiber TX/RX and analog audio in/out
- Up/down/cross conversion of 35+ formats
- 4 x 12G-SDI inputs and outputs, 4 x HDMI 2.0 inputs and outputs, handling signals up to 2160p60
- 4 x 3.5mm stereo headphone outputs, 4 x 3.5mm stereo line-in inputs
- 4Â x 1.3” OLED screen with status, video format, IP address, and more
- 4Â x scroll wheel button for direct menu operation as well as web UI control
- Audio embed/de-embed from stream, two-way intercom per channel
- 4 x RJ45 Gigabit Ethernet, 4 x optical fiber SFP+ interfaces (for optional 12G-SDI transceiver)
- AC power Inputs with 4 x LED illuminated power buttons
