Product Overview
1 x 4 3G/HD/SD-SDI Reclocking Distribution Amplifier gen2
The VDA-104-3GS provides reclocking distribution of an SDI video input signal to four SDI outputs. The input type, whether SDI, HD SDI or 3G SDI is auto detected and displayed via LED indicators.
- Supports 270Mb/s, 1.485Gb/s, and 2.97Gb/s data rates
- Supported video formats:
- SD: 480i59.94 "NTSC", 576i50 "PAL"
- HD: 720p24, 25, 30, 50, 59.94, and 60
- 1080i50, 59.94, and 60
- 1080p24, 25, and 30
- 3G: 1080p50, 59.94 and 60. Supports Level A and B
- 2K: 2048x1080p24 and 30
- Passes all ancillary data
- Reclocking function reshapes the signal to improve transmission distance
- Video format LED indication
- Provides automatic input cable equalization up to 300m (1000ft)@SD, 150m (500ft)@HD/3G
- Reclocking function reshapes the signal to improve transmission distance
- Compact metal housing
For more information on the Marshall 1 x 4 3G/HD/SD-SDI Reclocking Distribution Amplifier gen2, click here!
Warranty Information
All non-camera products are covered under a one (1) Year Standard Warranty (CV605, CV612TBI , CV612TWI, cameras have a one year warranty).
Two (2) Year Standard Warranty applies on the following models:CV500-series, CV228, CV343~CV374, CV355-27X-IP, CV355-27X-ND3, CV355-30X-IP, CV355-30X-NDI, CV355-10X, CV356, CV380, CV420-27X, CV420e, VS-PTC-200, VS-PTC-300, VS-PTCIP and all other camera equipment
Three (3) Year Warranty applies for all active CV620, CV625, CV630, CV730 models.
This warranty is extended to the first consumer only, and proof-of-purchase and/or serial number are required to honor the warranty. If there is no proof-of-purchase and/or serial number provided with a warranty claim, Marshall Electronics reserves the right not to honor the warranty set forth above. Therefore, labor and parts may be charged to the consumer. This warranty does not apply to the product exterior or cosmetics. Misuse, abnormal handling, alterations, damage or modifications in design or construction void this warranty. No sales personnel of the re-seller or any other person is authorized to make any warranties other than those described above, or to extend the duration of any warranties on behalf of Marshall Electronics, beyond the period described above. Due to constant effort to improve products and product features, specifications may change without notice. All “B” stock, “DEMO” stock, EOL, Obsolete products will have limited 90 day warranty. Marshall Electronics is not covering any cost associated with removal of the product, reinstallation, and other associated damages.
To submit a RMA request, CLICK HERE
