Science Image Studio Edge 2ch - 1RU Bi-Directional 4K Full NDI Encoder/Decoder

Science Image

Write a Review
Price: $5,302.00
SKU:
SCI-Studio-Edge-2CH
Condition:
New
Availability:
Ships direct from supplier. Usually available within 3-4 weeks pending availability.
Shipping:
Calculated at Checkout
More Info:
For more information or advice, please contact us at onair.au/contact-us
Product Link:
https://www.science-image.com/converters-en/studio-edge
Manufacturers Part Number:
Studio Edge 2CH
Science Image Studio Edge 2ch - 1RU Bi-Directional 4K Full NDI Encoder/Decoder - Image 1
Adding to cart… The item has been added

Product Overview

Studio Edge 2ch - 1RU Bi-Directional 4K Full NDI Encoder/Decoder

The Studio Edge 2-Channel Rackmount Bidirectional 4K SDI/HDMI/Full NDI Converter from SCIENCE IMAGE is a compact 1 RU short-depth chassis, featuring high-density, multi-channel NDI conversion capabilities. Ideal for studios requiring efficient management of numerous NDI sources and destinations within a single device, its blend of connectivity and performance is impressive. The Studio Edge series doubles as a display management system for digital signage, leveraging its integrated fiber connections to transmit video and audio over extended distances without signal degradation.

Driven by the same high-bandwidth NDI encoding and decoding engine found in the NDI Studio 4K. SH and STUDIO 2 standalone converters, the Studio Edge series offers identical connectivity within a rack-mountable chassis, powered by a single power supply. Each channel boasts independent power switches, LED displays, tally lights, video inputs and outputs, network connections, and audio ports. The unit supports VISCA and Pelco P and D support for use with compatible, separately available PTZ cameras.

Features at a Glance

  • 2-channel rackmount 4K Full NDI converter with fiber TX/RX and analog audio in/out
  • Bidirectional high-bandwidth NDI encoder and decoder
  • Up/down/cross conversion of 27 formats
  • 2 x 12G-SDI inputs and outputs, 2 x HDMI 2.0 inputs and outputs, handling signals up to 2160p60
  • 2 x 3.5mm stereo headphone outputs, 2 x 3.5mm stereo line-in inputs
  • 2 x 1.3” OLED screen with status, video format, IP address, and more
  • 2 x scroll wheel button for direct menu operation as well as web UI control
  • Audio embed/de-embed from stream, two-way intercom per channel
  • AC power Inputs with 2 x LED illuminated power buttons

Additional Details

  • 2-Channels SDI/HDMI In/Out
  • High-Bandwidth NDI 12G-SDI/HDMI 4K60 Bi-Directional Encoder & Decoder
  • At least 27-Format UpDown Conversion
  • 12G-SDI/HDMI 4K Optical Tranceiver
  • Audio Embeded/De-Embeded/NDI Tally
  • 12G-SDI In/Out HDMI 4K60 In/Out
  • Dual-Redundant 110-240V AC Power Supply
  • 1U Rack Mount
  • 2-Channels 1.3"OLED Screen
  • Independent Power Button for Each Channel
  • Control by Scroll Wheel Button/Dyna Hub/Web UI

For more information on the Science Image Studio Edge 2ch - 1RU Bi-Directional 4K Full NDI Encoder/Decoder, click here!

Warranty Information

12 Month Limited Manufacturer's Warranty. If you need contact us with an issue, please send an email to support@onair.com.au with the serial number or invoice number to create a support case.
