Product Overview
Studio Edge G 6ch - 1RU Bi-Directional 4K Full NDI Encoder/Decoder w/ Genlock
Encode and decode full NDI video with this Studio Edge G 6-Channel Bidirectional 4K SDI/HDMI/NDI Converter with Genlock from Science Image. This converter enables bidirectional encoding and decoding to and from six NDI streams and HDMI and 12G-SDI I/O.
Additional Details
- 6-channel rackmount full NDI converter with fiber TX/RX and analog audio input/output
- Bidirectional high-bandwidth NDI encoder and decoder
- Up/down/cross conversion of 27 formats
- Video I/O: Six 12G-SDI inputs and outputs, six HDMI 2.0 inputs and outputs
- Audio I/O: Six 3.5mm stereo headphone outputs, six 3.5mm stereo line-in inputs
- Genlock: Six genlock inputs
- Display: Six 1.3" OLED screens with status, video format, IP address, and more
- Control: Six scroll wheel buttons for direct menu operation, Web UI control
- Tally: Six tally LEDs compatible with NDI tally signals
- Resolution: Up to UHD/DCI 4K 2160p60
- Audio function: Audio embed/de-embed from stream, 2-way intercom per channel
- Network: Six RJ45 Gigabit Ethernet, six optical fiber SFP+ interfaces for optional 12G-SDI transceiver
- Power: AC power input, six LED illuminated power buttons
For more information on the Science Image Studio Edge G 6ch - 1RU Bi-Directional 4K Full NDI Encoder/Decoder w/ Genlock, click here!
Warranty Information
12 Month Limited Manufacturer's Warranty. If you need contact us with an issue, please send an email to support@onair.com.au with the serial number or invoice number to create a support case.
